This posts is merely an overview of what I did to get my WLAN guests, who access the Internet through the hotspot feature of the USG and the Unifi controller,through a VLAN so that they are not part of my own private network. (security)

This handout only applies when you gear of Ubiquity. (I have also other hardware, here you might have to make some configuration as well, my situation is explained.

What hardware is in the network
USG Router – US 8-150W switch – AC-Pro, 2 x AC-Lite AccessPoint (Unifi stuff)
1x TP-Link TLSG108E (Smart Switch)
2x Dump switch 5 port Netgear (not important in this story)
1x TP-Link TLSG2216 (Smart Switch)

1st Create a guest network with VLAN100. Do this only if you have the USG. If you do not have an USG this does not apply cause the network part in the controller is for use with the Unifi USG router.

If you use “Guest” it is already isolated from your corporate LAN.
Modify other settings like DHCP in this menu. This I do not explain.

Now make sure your SSID for your guests can be on a VLAN

This is the most important part.

Notice: I have an US-8-150W. When creating a VLAN Guest network in the profiles part of the controller the ports will be configured automatically. As long as you have all profiles accepted on the ports, the VLAN will directly work if your AccessPoint is directly connected to the Unifi Switch.

In my situation I have 2 AccessPoints behind a smart switch and 1 AccessPoint connected to a dumpswitch what is connected to the US-8-150W (all devices eventually come to the US-8-150W as the uplink is the USG Router).

A simple test towards the AP connected to the dumpswitch is showing that the VLAN is working

To have the VLAN100 working towards the other APs you need to tag the ports in other smart swiches. In my situation 2 different TP-Link devices

Tips for the TP-Link: TLSG108E: enable 802.1Q (no need to set the 802.1Q PVID setting)

In my example you see that port 1 and port 6 are tagged with VLAN 100. Port 1 is the uplink port towards the other switch (the unifi switch) and port 6 is the port towards the AccessPoint

Apply and save the configuration and your guests can access the guest portal over VLAN

the TP-Link SG2216 is a business smart switch so the screens are a little different

Here you see the VLAN section of the SG2216 where I tagged port 16 (uplink port towards the Unifi Switch) and port 10 connected to the AccessPoint. Now this AccessPoint is also serving VLAN towards my Guests.

Maybe you wonder what will happen to your normal LAN clients when you enable or tag ports on VLAN100: your normal LAN is not tagged and the switches will forward your data normally.

There is a nice tool for updating your db (mine is MySQL) with a tool called texturecache

this info is for my own purpose if useful use it

Crontab in place

0 */2 * * * sh /home/kodi/ > /dev/null 2>&1

echo “Start Scanning Video Library vscan”
/home/kodi/ vscan
sleep 5
echo “Start Cleaning Video Library vclean”
/home/kodi/ vclean
sleep 5
echo “Start update with qax”
/home/kodi/ qax
echo “Start scanning texturecache with function C”
/home/kodi/ c
sleep 5
echo “Prune data missing on disk P”
/home/kodi/ P
sleep 5
echo “Start update with Xd”
/home/kodi/ Xd
sleep 3
echo “Start update with ./ R”
/home/dennis/kodi/ R
sleep 3
echo “end”

Make sure that there is a connection with your “Master Kodi”
create a samba link in /etc/fstab ie. example
// /media/kodi cifs guest,uid=1000,iocharset=utf8 0 0
now the thumbnails can be saved correctly

I needed to expand my Windows 2008 R2 server with extra HDD data. I had an ISO available with VIOSTOR drivers (Virtio Storage) and autodetected the drivers. How could I be so stupid.

after reboot: BSOD and BSOD and stupid as I was I was unable to go back to ‘last good known configuration’.

first of all I had to pick the drivers for Windows 2008 from this location: ISO/viostor/2k8/(R2 if you have it)/amd64/viostor.*

To stop the BSOD from happening:

Find the viostor drivers (probably):


Rename Windows/System32/drivers/viostor.sys to System32/drivers/disabled.viostor.sys.disabled;

Similarly renamed both Windows/DriverStore/FileRepository/viostor.inf_amd64_neutral_b5a4b523b42ac3b3/viostor.sysand Windows/DriverStore/FileRepository/viostor.inf_amd64_neutral_e322cb56cfbcc209/viostor.systo disabled.viostor.sys.disabled

Then reboot.

Please be noticed that it can cost you a NEW license if you add this driver. Your hardware can be changed and it could be that Microsoft does not allow your key anymore.

upgraded ESXI to 6.5 U1 which is version 6.5.0 build 5969303

You are running HPE Customized Image ESXi 6.5.0 version 650. released on July 2017 and based on ESXi 6.5.0 Vmkernel Release Build 5310538

unfortunately the HP Microserserver Gen8 is than running with: HPE_bootbank_scsi-hpvsa_5.5.0.102-1OEM.550.0.0.1331820

As I was (and still am but as of writing I am in maintenance mode) seeing spikes in my CPU usages. It might be caused by the bad performance

checking with:
cd /vmfs/volumes/datastore1
time dd if=/dev/zero of=tempfile bs=8k count=1000000

It took a very long time to see some output. (Very long time!)

than I tried to downgrade to the driver


  1. enter maintenance mode
  2. I do a reboot, but you can do it probably without
  3. copy the downloaded driver to /tmp/ and run the following command
  4. esxcli software vib install -d /tmp/
  5. the old driver will be removed and the 5.5.0-88 driver installed
  6. Now important: if you do reboot this way: you will not see your DataStores anymore, only your NFS datastores (in my situation) this is caused by VMWARE ESXI as it will be using vmw_ahci driver for the datastore.
  7. so disable the usage of this ‘default’ driver: esxcli system module set –enabled=false –module=vmw_ahci
  8. now you can reboot and your device will be using the 5.5.0-88 driver
  9. you can see this by using; cat /proc/driver/hpvsa/hpvsa0

the speed should have been returned.


Wauw ..

yesterday and today I tried to upgrade my HP Microserver Gen8 from VMWARE ESXI 6.0.0 to 6.5
what a trouble ..

shut down all vms (hosts) and enter maintenance mode. If you do this there are a number of online blogs with help to install from online depots but in all my tests it was too slow or I was to impatient to wait to end. But in the end I always ended up with an system with errors:

the transaction is not supported: VIB Hewlett-Packard_bootbank_scsi-hpvsa_5.5.0-88OEM.550.0.0.1331820

Do not try to force the installation. You will end up with an system where it seems that your EXSI is updated to 6.5 but actually is is running in a ramdisk environment. Easy to see cause you have lost your datastores (NFS datastores are still mounted).

If you than reboot: you are back to 6.0.0 .. so how to solve this:

easy: when entering maintenance mode: reboot your machine. In many guidelines this part is not mentioned.

After I rebooted I first tried the online depot installation documentation but ended up waiting and waiting. I got a VMWARE image for update from VMWARE but I got all kinds of different issues again:

“The upgrade contains the following set of conflicting VIB” When using the standard image of VMWARE: many conflicting vibs a no go for me. So I read some blogs and I found out that it is best to keep using your HPE image vmware files. (So in short: if you used the HPE VMWARE ESXI ISO installing Esxi onto your HP Microserver Gen8 keep using the update files with HPE in it and not the plain VMWARE onces. It can give issues !

After I used the HPE image I only got 1 issue: one vib was still complaining. On this blog I read what I needed to do: remove this vib (partner supported, so not native).

After removing this VIB I could upload the various ZIP bundle files like

with the command:
esxcli software vib install -d “/vmfs/volumes/datastore1/patch-directory/”

I was able to install finally the 6.5 version. Due to issues of Storage driver I immediately updated to the U1 update
with the command:

esxcli software vib update -d “/vmfs/volumes/datastore1/patch-directory/”

the blog nxhut showed me some info that with the U1 version the storage speed performance issues should be over.

A simple test downloading a file towards a VM showed me a 18MB/s so the 10MB/s barrier was not seen.

A last reboot and get the machine out of maintenance mode. Finally I have a running 6.5U1.


Yeah .. wierd title

So in my case: I am at location A and I am making a VPN to my local network what is at location B

I can access all my local servers and computers, but one !

“The One” is a server which has a dedicated openvpn connection to location C, when this is active my VPN from location A cannot access “The One” at location B. Only when the OpenVPN connection is terminated

Solution: add a static route on “The One”

check with: ip route show

and add the route like this: ip route add via dev eth0

where is the VPN IP range what your local network is giving VPN users and via is the IP of your gateway (router)

… easy peacy ..

Nadat ik las dat Schiphol data van vertrekkende en landende vliegtuigen beschikbaar ging maken dacht ik: laat ik eens kijken of ik deze data ook kan verwerken in een website.

Na een paar weken stoeien is tie dan als een soort van 1st release beschikbaar: AroundMyRoom’s Schiphol page

Vooral het het begin lopen te stoeien hoe ik de JSON data kom omzetten in arrays en objecten. Met wat hulp van kwam ik daar wat verder mee.  Daarna liep ik best wel vast met wat for each loops en daar heeft Peter aka mijn mee kunnen helpen.

Op het laatst ging het bijna mis met de checkin balies, want ik wilde wat meer dan wat de API makkelijk mij kon voorschotelen. Ik maak namelijk een verschil tussen normale checkin-balies en andere soorten. Ik had het op basis van Type kunnen doen, maar ik koos onbewust voor de beschrijving waarbij hier vele verschillende schrijfwijzen voorbij kwam.  Door niet op te geven en door te blijven zoeken kwam ik wat functies tegen die ik kon gebruiken. De code is zeer zeker niet geoptimaliseerd, maar hey, het werkt ..

Wat ik als wens heb ik dat ik data wat sneller van de API zou kunnen krijgen / voorschotelen. Wellicht data tijdelijk in een DB stoppen zodat de data snel gepresenteerd kan worden. ..

Message to self: Important

When you create a userspace alike ODBC connection in Windows 2008 Server (whatever) it is likely that Access does not allow you to use linked tables as it is requiring a password.
Although you have the ability to store passwords in Access when linking tables through ODBC it is not always working when the ODBC connection is set in the field ‘user’ rather than Machine DataSource/System

The trick is to execute as admin the file c:\windows\SysWOW64\odbc32.exe
Then create the System ODBC connection towards the SQL database, return to your Access file and link the tables (and keep in mind to save the password as well when linking)

I tried above multiple times when the ODBC was in userspace or was (probably) not correctly created (32 versus 64 bits??)
Possible it can also be related that the application pool is 32bits rather then 64bits and the ODBC connection needs 32bits as well .. Hell: if this occurs again, you have some tips ;_)
